Description
| Build volume | 330 x 240 x 300 mm |
| (13 x 9.4 x 11.8 inches) | |
| Assembled dimensions | 495 x 500 x 1197 mm |
| (19.5 x 19.5 x 47.1 inches) | |
| Print technology | Fused filament fabrication (FFF) |
| Weight | 41.9 kg (92.4 lbs) |
| Power Input | 100 – 240 VAC, 50 – 60 Hz |
| Maximum power output | 600W |
| Layer resolution | 0.25 mm nozzle: 150 – 60 micron |
| 0.4 mm nozzle: 200 – 20 micron | |
| 0.6 mm nozzle: 300 – 20 micron | |
| 0.8 mm nozzle: 600 – 20 micron | |
| XYZ resolution | 6.9, 6.9, 2.5 micron |
| Feeder type | Dual-geared feeder, reinforced for composite materials |
| Display | 4.7-inch (11.9 cm) color touchscreen |
| Print core replacement | Swappable print cores |
| Print head | Dual extrusion print head with an auto-nozzle lifting system and swappable print cores |
| Nozzle diameters | 0.25 mm, 0.4 mm, 0.6 mm, 0.8 mm |
| Filter technology | Replaceable EPA filter |
| Air extraction rate | 1 – 50 m³/h (35 m³/h nominal rate for most materials at 23 °C) |
| Filter efficiency | Up to 95% |
| Material capacity | 6 spools |
| Compatible filament diameter | 2.85 mm |
| Compatible spools | Width: 50 – 70 mm (2 – 2.7 in) |
| Diameter: 197 – 203 mm (7.8 – 8 in) | |
| Core diameter: > 98 mm (3.8 in) | |
| Operating sound | < 51 dBA |
| Operating ambient conditions | 15 – 30 °C (59 – 86 °F), up to 70% relative humidity |
| Non-operating temperature | 0 – 32 °C (32 – 90 °F) |
| 3D printer operating parameters | For more 3D printer specifications: |
| Ultimaker S5 Product page | |
| Supplied free software | Ultimaker Cura – print preparation software |
| Ultimaker Connect – printer management software | |
| Cloud support | Ultimaker Cloud |
| Support OS | MacOS, Windows, and Linux |
| Plugin integration | SolidWorks, Siemens NX, Autodesk Inventor |
| Supported file types | Ultimaker Cura: STL, OBJ, X3D, 3MF, BMP, GIF, JPG, PNG |
| Printable formats: G, GCODE, GCODE.gz, UFP | |
| File tranfer | Wi-Fi, LAN, USB |
